نحوه فرمت کردن هارد و از بین بردن درایو ثانویه ( SmartWare دیسک درایو )
Data Lifeguard Diagnostics for Windows:
The first method of low level formatting your drive is to use our Data Lifeguard Diagnostics for Windows utility. Follow the instructions below for instructions on how to use this method:
- Download [ برای مشاهده لینک ، با نام کاربری خود وارد شوید یا ثبت نام کنید ] from the download page
- Install the application, and launch it from the Western Digital Corporation or WD Diagnostics folder on your start bar
- Carefully read the End User License Agreement.
- When you have finished reading the agreement, check the box titled I accept this License Agreement and click Next
- Highlight the drive you wish to erase.
Critical: Make sure you are selecting the correct drive. This process is Data Destructive and irreversible
- When you are sure you have highlighted the correct drive, click the Test button
- On the following screen select the WRITE ZEROS option and click Start
- You will now receive a prompt telling you to close all other applications that are running. Do this, and than click the OK button.
- Depending on the state of your drive you will receive one or two prompts reminding you that this action will destroy all data currently on the drive. If you are sure you want to do this, click Yes to each of them
- Next select which method you would like to use to write zeros. The QUICK ERASE option is much faster but does not fully wipe out the drive. This is ideal for users who are planning on re-using the drive. The FULL ERASE will fully wipe out the drive. This takes longer, but helps to ensure that no data on the drive can later be retreived using Data Recovery methods. This method is designed for people who are trying to wipe sensitive data from their disk. Once you have determined which method you would like to use, select the OK button to begin the formatting process.
Acronis WD Edition:
The second method of low level formatting your drive is to use Acronis WD Edition's DriveCleanser feature. Follow the instructions below for instructions on how to use this method:
To Download Acronis [ برای مشاهده لینک ، با نام کاربری خود وارد شوید یا ثبت نام کنید ] .
- Launch Acronis WD Edition from your start menu
- On the Select Task screen select Acronis DriveCleanser
- You will be taken to the Welcome screen. Click Next to continue
- The following screen is the Destination screen. Highlight the drive you wish to format and select Next
Critical: Make sure you are selecting the correct drive. This process is Data Destructive and irreversible.- Select Quick if you are not concerned about others later recovering data from the drive. If the information on the drive is of a sensitive nature or you are concerned about the data being recovered later select Normal. The Quick setting takes less time and writes zeros to the drive a single time. The Normal setting first fills the drive with data (ones) and than writes zeros over that to help prevent exisiting data from being recovered. When you have selected the method you wish to use press the Next button.
- The next screen is the Proceed screen. Verify the information in the white box and click the Proceed button to begin the low level format of the drive.
- The final screen is the Operation Progress screen. From here you can monitor the progress of the format. Depending on the capacity of your drive and the options you selected this can take a long time.
- When the low level format is complete you will receive an information popup window letting you know. Click OK to close this window and return to the main Acronis WD Edition screen
Data Lifeguard Diagnostics for DOS:
The third method to low level format a drive is by using Data Lifeguard Diagnostics for DOS. This application is run by burning an image to a CD, or by putting the files onto a bootable floppy disk.
To run the application from a bootable floppy disk follow the instructions below:
- [ برای مشاهده لینک ، با نام کاربری خود وارد شوید یا ثبت نام کنید ] the executable file to you Desktop
- Run the executable file
- Follow the prompts to create the bootable disk
- You can now boot to this diskette. Restart your system
- Make sure that your boot order in your BIOS is set to boot from the floppy drive first. If you need assistance doing this please contact your system or motherboard manufacturer
- When you boot to the diagnostics utility select the option WRITE ZEROS TO DRIVE
- Follow the prompts to select the drive, and if you want to do a Quick Erase or a Full Erase
To run the application from a writable CD follow the instructions below:
- [ برای مشاهده لینک ، با نام کاربری خود وارد شوید یا ثبت نام کنید ] the .iso file to your desktop
- You must use a CD burning program (such as Nero Burning Rom or EZ-CD Creator) to burn a CD from the .ISO image
- Make sure that your boot order in your BIOS is set to boot from the CD drive first. If you need assistance doing this please contact your system or motherboard manufacturer
- When you boot to the diagnostics utility select the option WRITE ZEROS TO DRIVE
- Follow the prompts to select the drive, and if you want to do a Quick Erase or a Full Erase
Data Lifeguard Tools:
If your drive was purchased prior to September, 2009 you have a fourth method for writing zeros to your drive. If you still have the CD that came with your hard drive you can use the Data Lifeguard Tools application to write zeros (low level format) your drive. For instructions on how to create a Data Lifeguard Tools 11 diagnostic disk, please see [ برای مشاهده لینک ، با نام کاربری خود وارد شوید یا ثبت نام کنید ] .
To write zeros to a hard drive using the diagnostic disk, please follow these steps:
- Boot your computer and set your system BIOS to boot to a floppy disk first. If you do not know how to enter or adjust your system BIOS please refer to your computer/motherboard user manual or contact the manufacturer.
- Save the new BIOS setting and insert the Data Life Guard diagnostic disk into your disk drive.
- You will be brought to the License Agreement screen, read the agreement and hit the Esc button.
- Press the Y key to accept the license agreement.
- You will be at the main menu for DLGDIAG 5.03. Use the down arrow button to highlight Write Zeros To Drive only after you have used the Select Drive option to choose the hard drive you wish to erase. If you only have one hard drive installed in your computer you do not need to select a drive.
- Press the Enter key.
- Press the F key to write zeros to the whole drive.
- You will be warned that all the data on the drive will be erased, press C to continue and erase the drive.
- Press Esc to go back to the main menu.
- Use your down arrow button to highlight Quit and press Enter.
External hard drives
Western Digital external hard drives only support writing zeros to the drive using the Data Lifeguard Diagnostics utility. In addition, if your drive includes the WD SmartWare software, you have a second option which does not write zeros to the drive, but does fully erase the drive.
Select the method you would like to use to low level format your drive:
- [ برای مشاهده لینک ، با نام کاربری خود وارد شوید یا ثبت نام کنید ]
- [ برای مشاهده لینک ، با نام کاربری خود وارد شوید یا ثبت نام کنید ]
Data Lifeguard Diagnostics for Windows:
To low level format (write zeros) to a WD external hard drive from within Windows (using Data Lifeguard Diagnostics), please follow the steps below:
- Download [ برای مشاهده لینک ، با نام کاربری خود وارد شوید یا ثبت نام کنید ] from the download page
- Install the application, and launch it from the Western Digital Corporation or WD Diagnostics folder on your start bar
- Carefully read the End User License Agreement.
- When you have finished reading the agreement, check the box titled I accept this License Agreement and click Next
- Highlight the drive you wish to erase.
Critical: Make sure you are selecting the correct drive. This process is Data Destructive and irreversible
- When you are sure you have highlighted the correct drive, click the Test button
- On the following screen select the WRITE ZEROS option and click Start
- You will now receive a prompt telling you to close all other applications that are running. Do this, and than click the OK button.
- Depending on the state of your drive you will receive one or two prompts reminding you that this action will destroy all data currently on the drive. If you are sure you want to do this, click Yes to each of them
- Next select which method you would like to use to write zeros. The QUICK ERASE option is much faster but does not fully wipe out the drive. This is ideal for users who are planning on re-using the drive. The FULL ERASE will fully wipe out the drive. This takes longer, but helps to ensure that no data on the drive can later be retreived using Data Recovery methods. This method is designed for people who are trying to wipe sensitive data from their disk. Once you have determined which method you would like to use, select the OK button to begin the formatting process.
Using WD SmartWare (Not a true low level format)
To fully erase your WD external hard drive using the WD SmartWare software (please note this is not a low level format), please follow the steps below:
- Start by launching WD SmartWare from the WD SmartWare folder on your start bar
- Once SmartWare is running click on the Settings tab and click Set Up Drive
- On the left click the Drive Erase button
- Read the warning message a check the I Understand checkbox
- Click on the Drive Erase button below the checkbox to begin erasing your drive
- You can see the status of the erase operation in the upper right corner of the WD SmartWare software
